ZKTeco – KR503E – Outdoor / Indoor Weigand ID Reader – 26 Bit – 125 KHz Prox Card Reader – Single Gang

The KR503E External 26 Bit Weigand ID Reader for 125 Khz Prox Cards The KR Series is the main accessory line of external Wiegand readers for all ZKTeco access control devices. With an elegant and robust design, they are easy to connect and install, and offer the possibility to control one door from both sides. The LED lights indicate allowed or denied access. They have a proximity reading range of up to 10 cm The fact that this series is waterproof, and the operating temperatures can range from -20 degree to +65 degree, it is the ideal solution for outdoor installation. Also they can be connected with our ZKteco controllers.Read range of up to 10cm(~4″) for proximity card External LED controlExternal Buzzer ControlIndoor/Outdoor operationSolid Epoxy pottedWaterproof IP65Reverse Polarity ProtectionCall 1-800-878-6604 for Dealer Prices!SpecificationsCard Support125 KHz Proximity Card ReaderRead Time<300msRead Distance10 cm ~ 4" InchesInput Port2 External LED Control2 External Buzzer ControlOutput Format26bit WiegandLED2 color LED indicator: red and greenBeeperyesPowerDC 6-14V/70mA(max)WaterproofingIP65Operating Humidity10% to 90% non-condensingOperating Temp°C: -10° to +70°CMountingSingle Gang – ~ 2-3/4" wideDownloadsData Sheet
