Seco-Larm – Access Control Digital Keypad – 1010 Users – Mullion Style – Weatherproof – Multi-colored Status LEDs

SLM-SK-2323-SDQ12~24 VAC/VDC operation1,010 Users (Output 1: 1,000 users, Output 2: 10 users)2 Form C relays, each rated 1 Amp @ 30VDCEach relay has programmable output time from 1~99 seconds or toggleOutput 2 can be programmed for use with a doorbell2 Egress inputs and 1 door sensor inputBacklit keys for easy nighttime use2 Multi-colored status LEDsAll features are programmed directly from the keypad – no need for an external programmerEEPROM memory protects programmed information in case of power lossOptical tamper sensor for added securityCircuitry is potted with epoxy for outdoor useSLM-SK-2323-SDQIP65 Weatherproof rating, rugged aluminum construction TypeMullion-Style Weatherproof Digital Access KeypadsNumber of User CodesUp to 1,010Operating Voltage12~24 VAC/VDCCurrent Draw – Standby64mA@12VDCCurrent Draw- Active1 Relay active: 92mA@12VDC 2 Relays active: 120mA@12VDCRelay Outputs (2)1A@30VDC, Form C, NO/COM/NCEgress Inputs2, N.O. GroundDoor Sensor InputN.C. GroundTamper SensorOpticalKeypad LED Life60,000 hours (over 6.8 years)Operating Temperature-4°~122° F (-20°~50° C)Dimensions6″ x 1-3/4″ x 15/16″ (152 x 44 x 24 mm)Weight11-oz (312g)Downloads:DatasheetManualDiagram
