Seco-Larm – Access Control Digital Keypad – 1000 Users – Weatherproof – Vandal Resistant – Flush Mount

12~24 VAC/VDC auto-adjusting operationUp to 1,000 possible user codes (000~999) programmable for output 1 and 100 (001~100) for output 2Up to 50 (01~50) possible temporary visitor codes, which can be programmed for one-time or limited-time use (1~99 hours)Output 1: Form C relay, 1A@30VDC max.Output 2: Transistor ground, 100mA@24VDCOutputs 1 and 2 can be programmed to activate for up to 99,999 seconds (nearly 28 hours)Tamper output: N.C. Dry contact, 50mA@24VDC maxMounts to standard single-gang back boxIP66 Weatherproof ratingKeypad illuminates when a button is pressed; backlight can be programmed for FULL or AUTO in standby modeAll features are programmed directly from the keypad: No need for an external programmerEEPROM Memory protects programmed information in case of power lossUp to 50 (01~50) duress codes for output 1, 10 (01~10) for output 2Duress code signals a silent alarm if an authorized user is forced to open the door under duressEgress input lets users exit the premises without keying in the codeDoor sensor input for anti-tailgating operationInterlocking input for connecting to a second keypad Operating Voltage12~24 VDC/VACCurrent Draw – Standby15mA@12VDCCurrent Draw – Keypress40mA@12VDCCurrent Draw – Output 1 Active65mA@12VDCCurrent Draw – Output 1 & 2 Active66mA@12VDCCurrent Draw – Total Max100mA@12VDCOutput- 2 Transistor Ground100mA@24VDCOutput 11A@30VDCOutput – Duress100mA@24VDCOutput – Interlock100mA@24VDCOutput- Tamper50mA@24VDCIP RatingIP66Input – EgressN.O. GroundInput – Door SensorN.C. GroundInput – Door InhibitN.O. GroundOperating Temperature-4°~158° F (-20°~70° C)Operating Humidity5~95% Non-condensingDimensions4-3/4″x3-1/8″x1-13/16″ (120x80x46mm)Weight16.2-oz (300g)Downloads:DatasheetManual
