TownSteel – XCE2020S – Electronic Push Button Lever Set – Clutch Lever Set – Satin Chrome – Grade 1

The XCE2020Sis a standalone electronic function lock that provides keypad technology integrated with ANSI Grade 1 heavy duty cylindrical lockset for greater security. Keypad technology simplifies the management of the system and provides ease of use. Maximum code capacity per lock includes 1 master code, 10 manager codes, 90 user codes and 5 service codes. It provides two remote control terminals; one for a fire alarm system and the other for remote release by push button.The XCE2000 Series is quick and easy to programWatch Programming Video HereMore Information Below Specifications Master Code Capacity per Lock1User Code Capacity Per Lock90Manager Code Capacity Per Lock10Service Code Capacity Per Lock5CommunicationMulti-colored LED and SoundPower Supply4AA batteriesBattery LifeUp to 2 yearsOperating Temperature-31° to 151° F (-35° to 66°C)Door Thickness1-3/4”-2”Backset2-3/4” standard,5”optionalTrimOutside lever has clutch mechanismTrim Style SentinelStrikeASA Strike standard, 1-1/4” X 4-7/8”Finish 626 – Satin ChromeLatch BoltStainless Steel, deadlocking, ½” projectionFaceplate1-1/8” x 2-1/4”EscutcheonWrought steel or zinc alloy, plated to match finish symbolsLeverCast zinc or stainless steel, plated to match finish symbolsCylinder Specifications6 pin Schlage “C” Keyway, standardCertificationsANSI/BHMA A156.2 — A156.2-2011 Grade 1 certifiedANSI/BHMA A156.25 — Meets or exceeds all applicable requirementsUL/ULC — UL 10C 3-hour ratedBAA — Meets guidelines of the Buy American ActADA — Meets requirements of the Americans with Disabilities ActRoHS — Meets requirements of EU RoHS Directive 2002/95/ECManufacturer Warranty1-year limited for electronic5-year limited for finish10-year limited for mechanical DownloadsInstallation Guide TemplatesProgramming GuideWatch Programming Video HereReturn Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Townsteel directly at 877-858-088, [email protected] or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
