Seco-Larm – Single Door Maglock – 600 lb Holding Force – UL Listed

The E-941Sx series of electromagnetic locks is the ideal way to secure a door against unauthorized entry. When power is applied to the electromagnetic lock, it creates an extremely strong magnetic field. The electromagnet is strongly attracted to the steel armature plate which is mounted on the secured door. Once the electromagnet is deactivated, the secured door will function normally without any residual magnetism.Features:Anodized aluminum housing (US 28) 12 or 24 VDC (selectable)No residual magnetismAdjustable mounting bracketMOV surge protectionComplete mounting hardware for typical installationsDetachable face plateUL and ULC listedCE listedLIFETIME LIMITED WARRANTYRoHS compliant Specifications:Holding Force600-lb (272kg)Operating Voltage12 or 24 VDCCurrent Draw500mA@12VDC, 250mA@24VDCOperating Temperature32°~120° F (0°~49° C)Electromagnet Dimensions9-13/16″x1-11/16″x1″ (250x43x25 mm)Armature Dimensions7-1/4″x1-1/2″x1/2″ (185x38x12 mm)Case Shipping Weight47-lb (22kg)Weight4-lb 6-oz (2kg)Case Quantity10 pcs Downloads:Spec Sheet:
