Seco-Larm – Electric Door Strike -Mini No Cut – Fail-secure – 12VDC – UL Listed

SLM-SD-991A-D1QConverts cylindrical lock sets into an electronic access-controlled locking systemFail-secure operation – Door remains locked if power to the strike is lost2-wire installation, non-polarized connectionStainless steel keeper for strength and long lifeIncludes Stainless Steel No-Cut and Silver-Colored Aluminum Low-Cut* Strike PlatesCan be used with virtually any cylindrical door locking systemCan be used with an optional digital keypad, pushbutton switch, and other entry devices.Suitable for office-type applicationsReversible non-handed design fits either right-hand or left-hand doorsShallow design for use with most metal doorsPowered by a solenoid, not a buzzer coilFor indoor use​Optional Bronze-Colored Aluminum Low-Cut* Strike Plate (SD-991RA-61Q/B) available:*Fits most metal or wood doors with minimum cutting of door frame beyond the hole for the strikeOperating Voltage12VDCCurrent Draw280mA@12VDCLatch Throw1/2″ (13mm)Static Strength1,000-lb (454kg)Endurance250,000 Cycles (Factory tested)Operating Temperature14°~120° F (-10°~49° C)Operating Humidity0~85% (Non-condensing)DimensionsStainless Steel No-Cut Plate: 2-3/4″x1-1/8″x15/16″ (70x28x24 mm)Downloads:DatasheetManualDiagram
