HID – 5365EGP00 – MiniProx Mullion Mount Proximity Reader – Wiegand – 18″ Pigtail(125 KHz)

The MiniProx® proximity card reader’s potted electronics enhance the securityof the reader. The slim, attractive design is ideal for indoor or outdoormounting.Accepts 5 to 16 volts, meeting most voltage requirements.Wiegandinterface.Includes 8″ Inch pigtailAllows easy upgrade from magstripe to a proximity reader; no rewiring or pulling of new cable required.Offers high reliability, consistent read-range and low power consumption in an easy-to-install package.Mounts directly onto metal with no change in read range performance.Provides multicolor LED, compatibility with all standard access control systems and internal or host control of LED and beeper.Includes multilingual installation manual. Typical Maximum Read RangeProxCard® II Card – up to 5.5″ (14 cm)ISOProx® II Card – up to 5″ (12.7 cm)DuoProx® II Card – up to 5″ (12.7 cm)Smart ISOProx®/DuoProx® cards – up to 5″ (12.7 cm)Proximity & MIFARE® Card – up to 5″ (12.7 cm)ProxCard Plus® Card – up to 2″ (5.1 cm)ProxKey® II Keyfob – up to 2″ (5.1 cm)MicroProx® Tag – up to 2.5″ (6.4 cm)*Depending on local installation conditions.Dimensions6.0″ x 1.7″ x 1.0″(15.2 x 4.3 x 2.54 cm)Power SupplyStandard MiniProx: 5-16 VDCHaz. Loc. MiniProx: 5-16 VDCLinear power supplies are recommended.Current RequirementsAverage: 30 mA (5 VDC); 20 mA (12 VDC)Peak: 110 mA (5 VDC); 110 mA (12 VDC)Operating Temperature-22° to 150° F (-30° to 65° C)Operating Humidity0-95% relative humidity non-condensingWeightWith terminal strip: 3.5 oz. (99 gm)With pigtail: 3.8 oz. (108 gm)Haz. Loc. MiniProx: 3.8 oz. (108 gm)Cable distanceWiegand interface: 500 feet (150 m)Recommended cable is ALPHA 1295 (22 AWG)5 conductor minimum stranded with overall shield or equivalent. Additional conductors may be required for LED or beeper control.DownloadsSpec SheetBrochure
