- Cast-Iron Construction — heavy-duty, cast-iron construction provides unmatched durability, withstanding the harshest conditions out in the field or at the job site
- High Performance — Fill-Rite’s trusted rotary vane pump technology delivers 75 liters per minute, perfect for filling large equipment with fuel tanks sized at 75-302 liters
- Stationary Tanks — powered by a 230V AC motor and equipped with a 2 inch bung mount, this pump is ideal for wiring to a standard 230 volt AC electrical supply and installing onto stationary aboveground tanks
- Reliable Technology — rotary vane technology naturally maintains its day one performance levels as it wears down from normal use, allowing for consistent performance over the entire life of the pump
- Long Life — thermally-protected motor prevents overheating, ensuring your pump performs for years without worry
- Equipment Safeguard — built-in mesh strainer filters out particulates in fuel, preventing damage to your equipment
- Limited Lifetime Warranty — we stand behind our product with an industry-leading Limited Lifetime Warranty to protect your investment
| Max Flowrate | 20 GPM / 75 LPM |
|---|---|
| Power Type | 220V AC |
| Compatible Fluids | Diesel, Kerosene, Biodiesel up to B20, Gasoline up to E15, Mineral Spirits, Heptane, Stoddard Solvents |
| Inlet Size / Connection / Thread | 1 ” / Female / BSPP |
| Outlet Size / Connection / Thread | 1 ” / Female / BSPT |
| Mounting Size / Thread / Type | 2″ / BSPT / Bung Mount |
| Duty Cycle (min) | 30 min on / 30 min off |
| Power Source | — |
| Motor Power (HP) | 0.33 |
| Max Current (A) | 2.4 A |
| Thermal Protection Switch | — |
| Self Priming | — |
| Suction Lift (ft.) | 15 ‘ |
| Dry Vacuum (in. Hg) | 11 |
| Operating Temperature Range (°F) | — |
| Discharge Head (ft) | 53 ‘ |
| Strainer Mesh Size (Micron) | 40 x 40 x .010″ |
| Max Discharge Pressure (PSI) | 23 PSI |
| Viscosity Range (cSt) | 0.38 – 2.4 |
