*Discontinued* Dahua / HDCVI Balun / Passive / 1 Channel / DH-PFM800-E

DH-PFM800-EOne (1) Channel BalunReal-time Transmission over UTP CAT 5E/6 CableExternal Power Supply not RequiredFive-year Warranty (for products sold through an authorized Dahua Dealer)Become a registered dealer of DahuaCall 1-800-878-6604 for Dealer Prices! Technical Specification VideoTransmission SignalOne (1) ChannelMaximum Transmission DistanceHDCVI720p: 400m (1312.34ft)1080p: 250m (820.21ft)Category TypeUTP CAT 5E/6Video Transmission Properties and PortsCoaxial Video ConnectorBNC-MTwisted-pair Video ConnectorPush-terminalCompatible FormatHDCVI, AHD, TVI, CVBSResolution720p, 1080pAnti-interference> 60 dBProtectionESD1a contact discharge electricity level 31b air discharge electricity level 3Per: IEC61000-4-2Coaxial Cable Connector2 KV (common-code) per IEC1000-4-5UTP Cable Connector2 KV (different-code), 4 KV (common-code),per IEC1000-4-5ImpedanceBNC Male75 ΩUTP Cable100 ΩPhysical PropertiesDimensions180.0mm x 19.0mm x 16.0mm(7.09in. x 0.75in. x 0.63in.)ShellABSColorBlackNet Weight0.042 kg (0.09 lb)StabilityMTBF> 10000 hEnvironmentalOperating Temperature–10 °C to +55 °C (14 °F to 131 °F)Storage Temperature–20 °C to +70 °C (–4 °F to 158 °F)Humidity0 to 95%, non-condensing DimensionsApplicationDownloadsData Sheet
